POLİMAK TEST FACILITY

  • Emre Karatekeli
  • December 26th, 2024

At POLİMAK, we are committed to innovation in bulk material handling to meet the ever-changing demands of the industry. We are excited to announce the opening of a new testing facility next to our factory. This facility will allow us to develop and refine solutions tailored to the unique needs of our customers.

Launching our test facility will help us to deal with a diverse set of bulk material handling solutions, including silos, loading bellows, container filling and discharging systems, pneumatic conveying systems, airlocks, and big bag unloading systems.

POLİMAK‘s cutting-edge technologies enable a specific approach to each customer’s needs. With this advantage, we can reduce waste, increase efficiency, and boost overall productivity. We are ready to deliver maximum value to our clients by providing them with high-productivity equipment.

From Container to Silo and Back – A Smooth Process for Both Ends: Producer and User

Recently, we partnered with an industry-leading customer to test our integrated systems. The results were outstanding, with no issues encountered. Here’s how it works:

  1. Tiltless Container Discharger with Optimized Pneumatic Conveying
    By using POLİMAK’s blower and airlock systems, transferring the material from the container discharger to the silo becomes easy. Whilst the blower generates the required airflow for material transport, the airlock maintains pressure and ensuring a continuous flow.
  2. Reloading with Optimized Technology
    After being stored in the silo, the material is efficiently transferred back into a container through our screw conveyor loader. This process guarantees dust-free loading with precise control, boosting operational efficiency.

By integrating Polimak’s pneumatic conveying systems with cutting-edge container solutions, we provide a durable and safe closed-loop system that ensures the rigorous standards of industry leaders.
